Product Description:
Protective Features: Off-road adventures can be unpredictable, so
this motorcycle includes protective features to minimize potential
damage. Features such as reinforced handguards, skid plates, and
sturdy frame protectors shield the motorcycle from impacts,
branches, and debris, ensuring durability and longevity.
Easy Maintenance: This motorcycle is designed with ease of
maintenance in mind. Accessible components and user-friendly design
elements make routine maintenance tasks, such as oil changes and
filter replacements, straightforward and hassle-free, allowing you
to spend more time enjoying your off-road adventures.
Technical Parameters:
| Engine | |
| Engine Type: | Single cylinder,air-cooled,four stroke, |
| Displacement (ml): | 149 |
| Bore X Stroke(mm): | 62×49.5 |
| Compression Ratio: | 10.3:1 |
| Max. Power (kw/r/min) | 9/8500 |
| Max. Torque (N.m/r/min): | 11.0/7500±500 |
| Max. Speed (Km/h): | ≥85 |
| Lubrication: | Pressure ,splash |
| Clutch Type: | Multiplate wet clutch, Manual |
| Ignition: | CDI |
| Starting System: | Electric/Kick Start |
| Transmission System: | Chain drive |
| The left and right steering angle | left 39º right 40º |
| CHASSIS | |
| Front Brake: | disc/drum brake |
| Rear Brake: | drum brake |
| Front Tire: | 2.75-21 |
| Rear Tire: | 4.10-18 |
| Battery: | 12V/7AH |
| DIMENSIONS | |
| L X W X H (mm): | 2080×830×1120 |
| Seat Height (mm): | 850 |
| Wheelbase (mm): | 1300mm |
| Min. Ground Clearance(mm): | 200 |
| Max. Permissionable Weight (kg): | 165 |
| Rider Capacity: | 2 Person |
| Dry. Weigth (kg): | 115 |
| Engine Oil (L): | 1L SAE15W/40 |
| Fuel Tank Capacity (L): | 11 |
| Roll angle (°) | 10° |
Pictures:
Packing and Shipping:
Full Container Shipping
We always recommend our buyers to start with 1x40HQ(at least 1x20GP
for trial order). Full container loading can reduce the
cost, give products the best protection, and help to orgnize
producing.
1 Year of 6000km Guarantee:
We are confident to ensure our quality to our buyers, long time
guarantee helps to build our business, and build good image into
our buyers group. We are happy to do that, and always continue.
